| General |
|
Product Type
|
Smartphone |
|
Form Factor
|
Touch - Rugged |
|
Protection
|
Dustproof, waterproof, sandproof, thermal protection, dirtproof, drop-proof, vibration-resistant, salt mist protection, pressure resistant |
|
Integrated Components
|
Front-facing camera, FM radio, audio player, voice recorder, navigation, dual rear-facing camera |
|
Width
|
3.1 in |
|
Depth
|
0.5 in |
|
Height
|
6.4 in |
|
Weight
|
8.82 oz |
|
Body Material
|
Aluminium reinforced die-cast frame |
|
SAR Value
|
1.594 W/kg (body) / 0.416 W/kg (head) |
| Cellular |
|
Technology
|
WCDMA (UMTS) / GSM |
|
Mobile Broadband Generation
|
4G |
|
Service Provider
|
Not specified |
|
Operating System
|
Android 8.0 Oreo |
|
Navigation
|
GPS, GLONASS, Galileo, QZSS, SBAS |
|
SIM Card Type
|
Nano SIM |
|
SIM Card Slot Qty
|
Dual-SIM |
|
Payment Technology
|
Android Pay |
|
Input Device
|
Multi-touch |
| Messaging & Internet |
|
Messaging Services
|
SMS, MMS |
|
Supported Social Networks and Blogs
|
Yes |
| Communications |
|
Data Transmission
|
GPRS, EDGE, HSDPA, HSUPA, HSPA+, FDD-LTE, TDD-LTE |
|
2G Band
|
GSM 850/900/1800/1900 |
|
4G LTE Band
|
Band 1, Band 2, Band 3, Band 5, Band 7, Band 8, Band 19, Band 20, Band 26, Band 28, Band 38, Band 39, Band 40, Band 41 |
|
4G LTE Frequency
|
FDD 2100, FDD 1900 PCS, FDD 1800+, FDD 850, FDD 2600, FDD 900, FDD 800 upper, FDD 800 DD, FDD 850+, FDD 700 APT, TDD 2600, TDD 1900, TDD 2300, TDD 2500 |
|
Wireless Interface
|
IEEE 802.11b/g/n, NFC, Bluetooth 5.0 |
| Phone Features |
|
Phone Functions
|
Speakerphone, call timer, conference call, flight mode, vibrating alert |
|
Sensors
|
Accelerometer, ambient light sensor, proximity sensor, digital compass, barometer, gyro sensor, laser distance sensor, Indoor Air Quality Sensor (humidity & temperature) |
|
Additional Features
|
Notification LED, Wet Touchscreen Operation, Glove Touchscreen Operation, MSX technology, laser assisted distance measurement |
| Processor |
|
Type
|
Qualcomm Snapdragon 630 |
|
Clock Speed
|
2.2 GHz |
|
Processor Core Qty
|
8-core |
|
64-bit Architecture
|
Yes |
| Graphics System |
|
Graphics Accelerator
|
Qualcomm ADRENO 508 |
| Memory |
|
RAM
|
4 GB |
|
Internal Memory Capacity
|
64 GB |
|
Supported Flash Memory Cards
|
microSD |
| Front Camera |
|
Sensor Resolution
|
8 Megapixel |
|
Focus Adjustment
|
Focus free |
| Rear Camera |
|
Sensor Resolution
|
16 Megapixel |
|
Focus Adjustment
|
Automatic |
|
Light Source
|
Dual LED flash |
|
Video Resolutions
|
3840 x 2160 (4K) at 30 fps |
|
Features
|
Phase Detect Auto-Focus (PDAF) |
| Second Rear Camera |
|
Sensor Name
|
FLIR Lepton |
|
Features
|
FLIR Thermal Camera, FLIR MSX image resolution, Live Streaming of thermal images |
| Display |
|
Type
|
LCD display |
|
Technology
|
IPS |
|
Diagonal Size
|
5.2" |
|
Display Resolution
|
1920 x 1080 pixels |
|
Display Format
|
Full HD |
|
Protection
|
Corning Gorilla Glass 5 (scratch resistant glass) |
|
Features
|
Super Bright Display |
| Connections |
|
Connector Type
|
USB Type-C - 24 pin USB-C Headset jack - mini-phone 3.5 mm |
| Battery |
|
Technology
|
Lithium ion |
|
Capacity
|
4500 mAh |
|
Fast Charging Technology
|
Qualcomm Quick Charge 4.0 |
|
Talk Time
|
2100 minutes |
|
Run Time Details
|
Talk (3G): up to 2100 min Standby: up to 888 hrs |
| Miscellaneous |
|
Compliant Standards
|
MIL-STD 810G, IP68, IP69 |
|
Included Accessories
|
Power adapter |
| Manufacturer Warranty |
|
Service & Support
|
Limited warranty - 2 years |
| Environmental Parameters |
|
Max Depth of Water Resistance
|
10 ft |
|
Max Height of Shock Resistance
|
6 ft |
|
Min Operating Temperature
|
-13 °F |
|
Max Operating Temperature
|
131 °F |
| Universal Product Identifiers |
|
Brand
|
CAT |
|
Part Numbers
|
CAT-S61, CS61-DAB-ROW-EN, S61 |
|
GTIN
|
00810296024679 |
